54m Offshore Support & Construction Vessel for Sa

54m Offshore Support & Construction Vessel for Sale / #1070110 54m PSV well maintained and in class.



Storage:

Clear Deck : 150 m²

Freezer : 4 m³ below deck

3x 20-ft Reefer container on deck

Dry Storage : 20 m³ below deck



Deck Equipment:

Anchor Windlass : 1x Hydraulic 10 Ton @ 15 m/min

Brake holding 31 Ton

Tugger Winch : 1x Hydraulic 10 Ton

Capstan : 2x Hydraulic 5 Ton



Lifting Equipment:

Deck Crane : 1x TTS, GP320

10 Ton SWL @ 15 mtr

A Frame(stbd) : 1x TTS HL 9D 10 Ton SWL

MOB Crane : 1x SVM, 2.0 Ton SWL



General details as follows:

LOA 53,8 m

Beam 13,8 m

Draft 3,8 m



Built in year 2008

Class : Registro Italiano Navale

Flag : Panama

Gross Tonnage of 1.076 and Nett Tonnage of 322



Free Deck area about 150m²

1 Crane / Gear installed with a max lifting capacity of 10 tons

1 Crane / Gear installed with a max lifting capacity of 2 tons

1 AF installed with a max lifting capacity of 10 tons

Deadweight : 1.126 metric tonnes

Bollard Pull : 40 tons

Capable of supplies of 1.133m³ Fuel Oils and 208m³ FW



Total 42 berths

4 cabins with 1 berth

2 cabins with 3 berths

8 cabins with 4 berths



Speed : 11 knots

Engines : 2 x Cummins / Cummins Engine Co Inc KTA-50-M2, 2.500 kw, 1.800 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)

Auxiliaries Engines : 3 Caterpillar 260 kw, Bowthruster + No Sternthruster (1 Bow Tunnel thruster 427kw Schottel STt 330 LK 5 ton)
