1996

Cargo capacity: 2308 lane meters or 644 TEU or 157 Trailers TEU: WD: 246 pcs MD: 288 pcs LH: 110 pcs Lanemeters: WD: 1006 m MD: 882 m LH: 420 m WD with 246 TEU: 436 m Trailers: WD: 68 pcs MD: 61 pcs LH: 28 pcs Sq. Meters: WD: 3186 m2 MD: 2943 m2 LH: 1351 m2 Total: 7480 m2 Lane widths: WD: 3,00 m MD: 3,15 m LH: 3,15 m Axle load deck: 16 t, MAFI 32 t, or 3 t/m2 Reefer outlet: 440 Volt LH 16 pcs, MD 40 pcs, WD 24 pcs Note plugs in LH not to be used at same time as them on WD Pax capacity: 12 pax in 4 cabins Free heights: Weather deck: Height under flume tank: 4,75 metres Height in garage: 6,25 meters Main deck: Height: 6,10 meters Lower deck: Height: 5,80 meters Height 1 meter from ship sides: 5,20 meters Ramps: Stern ramp: Height: 6,10 meters, width: 13,00 meters, length: 15,53 meters Flaps 3,00 meters Max load: 3 t/m2 Side ramp: Height: 6,10 meters, Width: 8,00 meters, length: 15,53 meters Flaps 3,00 meters Max load: 3 t/m2 Bulck head door: Height: 6,10 meters, width 7,00 meters Ramp to weather deck: Height: 5,90 meters Ramp to lower hold: Height: 4,60 meters, width: 3,51 meters Crane: 1 x MacGregor, type GL 3626-2 SWL: 36 ton Outreach: 3,2 - 26,00 meters Location: Weather deck stb. Side Stabilizers: Flume tank Location: Weather deck midships Anchor chains: Port: 10 shackles Starboard: 11 shackles Service speed: 18,5 knots Main engine: MAN B&W 8L 58/64 S/N 1110149 Output: 11120 kW Sharft generator: Yes Fuel: RMG 380 DMA 0,1%S RMD80 ULSFO 0,1%S Consumption: 23,00 ton/24 Hours at 12 kn 29,00 ton/24 Hours at 14 kn 35,00 ton/24 Hours at 16 kn 41,00 ton/24 Hours at 17 kn 47,00 ton/24 Hours at 18 kn 58,00 ton/24 Hours at 19 kn Aux. eng: 2 x Caterpillar type 3512 Output: 1070 kW 440 Volt 60 Hz Fuel: DMA 0,1%S Consumption: 3,00 ton/24 Hours Propeller: 1 x C.P.Propeller, Berg 1360 HX/4 HDX-60 ERC 2000 Rudder: 1 x Becker, type: FKSR - 1 - 3550/960/670/1 Steering gear: Ulstein Frydenbö HS 180-03 Bow thrusters: 2 x Berg SP-8 ERC 1000 590 kW Stern thruster: 1 x Berg SP-8 ERC 1000 680 kW LOA 183.27 m Beam 25.2 m Draft 7.35 m Built in year 1996 Class : Lloyd's Register Flag : Denmark (DIS) Gross Tonnage of 18,725 and Nett Tonnage of 5,617 2 Decks total 2,308 Lane meters Total passenger capacity 12 Deadweight : 13,500 metric tonnes 1 Crane / Gear installed with a max lifting capacity of 35 tons Speed : 18 knots Engines : 1 x MAN / MAN B&W Diesel A/S 8L58/64, 11,120 kw, 428 rpm, Propellers 1 Controllable Pitch (Center) Auxiliaries Engines : 2 Caterpillar 1,110 kw, Bowthruster + Sternthruster (2 Bow Thwart. CP thruster 600kw + 1 Stern Tunnel thruster), Boilers : 1 x Aux Service + 1 x Ex Gas Ecn
