Lagoon 570 Catamaran – Year 2004
The Lagoon 570 is a premium cruising catamaran built in 2004 by the renowned French shipyard CNB Lagoon (part of Groupe Beneteau). Introduced in the early 2000s, the 570 was designed for long-distance cruising, offering both performance and comfort for private owners or crewed charters. ex-charter catamaran complete refit by a professional Completion of the work in 2023 French flag EX VAT, available in Martinique
Interior layout:
This Lagoon 570 is offered in three cabins with private shower rooms, spacious saloons, large galley long shape in the port hull, configured for private use.
Highlights:
Exceptional space and quality marine-grade finish.
High autonomy (large tanks, solar panels, genset, etc.).
Strong offshore performance, ideal for Bluewater cruising
If you would like more information, a detailed brochure or advice for buying or renting this catamaran, do not hesitate to contact us
Three-cabins version
Starboard hull:
Owner suite
Double bed 160X200 with fan and e-reader and USB sockets
Desk and plenty of storage space
Shower room with shower, sink and Vetus electric toilet and holding tank.
Port hull:
Aft cabin 160X200 with fan and e-reader and USB sockets
Desk and plenty of storage space
Shower room with shower, sink and Vetus electric toilet.
Forward cabin double bed 150X200 with fan and e-reader and USB sockets
Shower room with shower, sink and Vetus electric toilet.
Water tank 2X400L
Aqua base 100L/h water-maker
Pressurized hot and cold water.
Quick stainless steel water heater 50L
Pressurized seawater
New 2023 fans in cabins
New 2023 Interior upholstery
New 2022 Lofran’s electric windlass
Korba 35 Kg main anchor with 12 mm chain 50m
New 2023 trampolines
New 2023 Flexiteek cockpit floor and aft transom
Remove cockpit table.
Fridge and freezer 60L
Deck shower
Swim ladder
Stainless steel double sink
Pressurized cold hot water.
Three-burner hobs with oven
Webasto Cruise stainless steel refrigerator
Ceramic worktop
Electronics :
Raymarine i70S central navigation log, speedometer depth sounder, wind speed and wind direction
Two multifunction screens at the helm station and a repeater at the chart table
Ray63/73 fixed VHF chart table and helm station
Raymarine Axiom+12 GPS Plotter Multifunction Display
AIS 700 Class B Receiver
Autopilot Evolution EV 400Sail P70s+ACU400
Electrical:
Service batteries Lithium Kilo Vault 2X330A/24v
Three 355w solar panels on carbon dinghy davits
Two Victron MPTT 150/70 controllers
One Victron 70A 12/24v charger
One Victron inverter multi 24/230//3000X
Victron BMV 712 batteries monitor
Full Mantagua LED Lighting
Quick Blue LED courtesy Lighting
New 2022 Volvo D2-75 inboard engine and sail drives
Three-layer epoxy primer
Four-layer coppercoat (antifouling)
